Backed by the trust of Archidply, this HDF board is strong, sturdy, tough and boiling water-proof. Its unique selling proposition (USP) is its extremely high density of 1000 kg/m3 and its boiling water-proof properties. Developed by our state of the art R & D lab, this board is designed to meet the specific needs of kitchens and damp areas. Its extreme high density makes it ideal for interior applications in wet conditions, high load-bearing surfaces, high traffic areas, and areas with high temperatures. This is a truly excellent, all-season product. The superior performance of these boards has successfully dispelled traditional myths about plywood’s toughness and longevity.

At Archidpanel, we are committed to staying ahead of the latest trends in the wooden panel market with high quality innovations and Boilshield stays true to that commitment. Manufactured at Archidpanel’s state-of-the-art facility in Sitarganj, Uttarakhand, it extends the Archidpanel range of high-performance HDF solutions by guaranteeing exceptional strength across diverse applications and proven resistance to moisture-induced swelling. This product meets the stringent thickness swelling and bond integrity standards required for the industry’s top-tier BWP (Boiling Water Proof) classification and is proven to be resilient and durable in challenging conditions.

Standard Size
8ft x 4 ft (2440mm x 1220mm), 8ft x 4 ft (2440mm x 1220mm), 8ft x 6ft (2440mm x 1220mm), 8ft x 4ft (2440mm x 1220mm), 8ft x 4ft (2440mm x 1220mm)
Thickness
7.5mm, 12.00mm, 12.00mm, 16.00mm, 18.00mm
GRADE
BWP-HDF
VARIANT
Plain & Pre-Lam

Application
Areas
Heavy Storage Areas bearing weight of 50-100 kg.

Restroom Toilet Cubicle

Thermal Insulation

Load Bearing Area – Decking / Warehouse Shelves/ Staircases

Container Floor

Bathroom Partition

Wall Paneling

Furniture

Modular Kitchen

Moist Area Furniture

Technical Details

BOILO-BWP FR (FIRE RETARDANT) HDF BOARD (FEATURES AND BENEFITS)

Feature Benefits
BWP Boiling Water Proof
Fire retardant property confirming to IS:5509 Standard Fire retardant
Borer Proof Protection Against Borers
Termite proof (1 Year testing Certificate from IPRITI) Resistant to termites
High Density
  • Superior strength
  • Enables intricate routing and carving
Smooth Surface Ideal for painting and polishing
High surface density of 1180kg/m3
  • High impact resistance
  • Enhanced Dent resistance
  • Improved paint coverage with minimal absorption
  • Reduced glue consumption and post-lamination
Uniform Thickness Ensures Bubble free Pre-Lamination & Post-lamination
Homogenous structure- across the grain and along No core gaps or core overlaps, providing uniform quality
Black color Can be polished-used as coloured HDF
Available in 8’X6′ (12mm) Reduction in cutting wastage
High rigidity (6 times higher than requirement of structural plywood IS:10701) Exceptional Load bearing capacity
High bonding strength
  • Long Lasting durability
  • Strong internal bonding and excellent screw holding capacity, unaffected even in boiling water
High Dimensional Stability
  • Lower water absorption
  • Reduced thickness swelling
  • Minimal linear expansion
Features
https://archidpanel.com/wp-content/uploads/2024/06/warranty-1.svg
25 Years Warranty
https://archidpanel.com/wp-content/uploads/2024/06/moisture-resistant-2.svg
Boiling Water Proof
https://archidpanel.com/wp-content/uploads/2024/06/superior-quality-1.svg
Heaviest Density 1000 kg/m
https://archidpanel.com/wp-content/uploads/2024/06/high-density-2.svg
Tougher Than Plywood
https://archidpanel.com/wp-content/uploads/2024/06/flat-surface-1.svg
High Strength Bonding
https://archidpanel.com/wp-content/uploads/2024/06/tropical-weather-resistant_1.svg
Waterproof Glue
https://archidpanel.com/wp-content/uploads/2024/06/termite-resistant-2.svg
Kills 99.99% Bacteria, Virus & Other Microbes
https://archidpanel.com/wp-content/uploads/2024/06/splinter-1-1.svg
100% Hardwood
https://archidpanel.com/wp-content/uploads/2024/06/ultra-smooth.svg
Smooth Surface
https://archidpanel.com/wp-content/uploads/2024/06/termite-resistant-2.svg
Borer and Termite Proof
https://archidpanel.com/wp-content/uploads/2024/06/screwholding-1.svg
High Screw Holding Density
